Laboratory Press Molds
Infrared Heating Quantitative Flat Plate Mold for Precise Temperature Control
Item Number : PMHD
Price varies based on specs and customizations
- Die heating
- 0.0℃-300.0℃
- Sample size
- Φ25mm~Φ50mm (d)
- Sample thickness
- 15-100μm~25、50、100、250、500μm
Shipping:
Contact us to get shipping details Enjoy On-time Dispatch Guarantee.
Infrared Heating Quantitative Flat Plate Mold: Precision and Efficiency for Your Lab
KINTEK specializes in advanced lab press machines, including automatic lab presses, lab isostatic presses, and heated lab presses, designed to meet diverse laboratory needs. Our Infrared Heating Quantitative Flat Plate Mold system embodies this expertise, offering precise and efficient heating for your critical applications.
Discover the key components and processes that make this system a valuable asset in your laboratory:
Advanced Control and Features for Optimal Performance
Our Infrared Heating Quantitative Flat Plate Mold technology leverages advanced materials and precise temperature control to deliver exceptionally uniform heat distribution across your samples. This ensures consistent results and reliable material processing. Key features include:
- Uniform Heat Distribution: Achieved through advanced materials and precise temperature control, crucial for consistent sample treatment.
- Effective Thermal Management: High-performance insulation layers, including high-temperature ceramic fiber boards and zirconia fiber blankets, minimize heat loss and maximize energy efficiency.
- Enhanced Precision and Safety: An integrated PID controller with SCR power control and auto-tune functions ensures reliable, consistent performance and operational safety.
- Optimized Heat Conduction: The innovative one-piece platen heater, incorporating a swaged tubular element, optimizes heat conduction for rapid heating and simplifies assembly, contributing to durability and ease of maintenance.
- High-Temperature Stability: Constructed with high-quality ceramic and quartz materials, the infrared heaters offer exceptional stability even at high temperatures, ensuring longevity for demanding applications.
The intuitive operation interface provides comprehensive control over the heating process:
- Standard interface: You can set the mold heating temperature and constant temperature time separately in this interface.
- Water cooling button: The water cooling machine power supply is connected to the thermostat, and the thermostat can control the opening and closing of the water cooling machine.
- Heating button: You can start heating the mold.
- Stop button: You can stop the heating of the mold.
- Timing switch: You can turn the timing function on and off.
- Start button: You can heat up according to the multi-stage heating program.
- Stop button: During the heating process, you can stop the heating process.
- List curve: You can switch the current display state, list and curve chart.
Ready to enhance your laboratory's capabilities with precise and efficient heating? Contact us for a consultation or quote using the form below.
Technical specifications
| Instrument model | PMHD-A | PMHD-B |
|---|---|---|
| Sample shape |  |
|
| Die heating | 0.0℃-300.0℃ | 0.0℃-300.0℃ |
| Die material | Alloy tool steel :Cr12MoV | Alloy tool steel :Cr12MoV |
| Sample size | Φ50mm (d) | Φ25mm (d) |
| Sample thickr | 15-100μm | 25、50、100、250、500μm(6 measuring loops) |
| Dimensions | 200*60mm (D*H) | 200*60mm(D*H) |
| Weight | 220V/300W | 220V/300W |
| Diagram of hydraulic powder press size |  |
 |
Versatile Applications
Infrared heating quantitative flat plate molds are versatile tools designed for a wide range of applications, particularly in industries and research settings that require precise and efficient heating processes. These applications benefit from rapid energy transfer and the ability to control heating zones effectively, making our system ideal for material science, sample preparation, and quality control procedures.
Operation steps
1. Set the temperature for heating the upper and lower molds.
2. Click the upper and lower plates to start heating.
3. Put the sample into the mold first.
4. Put the mold into the tablet press for pre-compression.
5. When the temperature reaches the set temperature, start pressurizing the mold.
6. Turn off the heating function and let the sample cool.
7. Remove the heated mold.
8. Take out the pressed sample.
Partner with KINTEK for Your Laboratory Needs
KINTEK is committed to providing high-quality, reliable lab press machines and accessories that empower researchers and technicians. Our Infrared Heating Quantitative Flat Plate Mold is a testament to this commitment, designed for precision, efficiency, and ease of use.
For detailed specifications, to explore custom configurations, or to discuss how this system can integrate into your specific application, please contact us through the form below. Our expert team is ready to assist you in finding the perfect solution for your laboratory.
Full range of types of laboratory press molds
We have a full range of molds for you to choose from, and the molds fit the body perfectly.
If you need molds with special shapes, we can also customize them for you.
